The 275 GTB/4, unveiled in October 1966 at the Paris Motor Show, was built on the chassis of the earlier 275 GTB and primarily introduced mechanical improvements. The Colombo V12 Tipo 226 received quad overhead camshafts (hence "4-Cam") and six Weber carburetors, with output rated at 300 hp. Visually, it can be identified by the hood bulge necessitated by the taller engine. The claimed top speed was 268 km/h. By 1968, 330 units had been built.
Summarized from the sources cited below; every figure in the text was automatically verified against the sources.
Learn moreTechnical details · Body and chassis
Technical details
The Tipo 226 is a Colombo V12 displacing 3285.72 cm³. It was developed from the Tipo 213 of the earlier 275, which had two valves per cylinder. New additions included quad overhead camshafts and six Weber 40 DCN carburetors as standard. The valve angle was reduced by three degrees to 54°, making the heads more compact. Thanks to twin camshafts per bank, the valves could be positioned perpendicular to the shaft rather than offset. Lubrication was dry-sump with a large oil capacity of 16 liters.
Body and chassis
The body built by Scaglietti largely corresponded to the long-nose Series II model of the 275 GTB. The most noticeable difference is the bulge on the hood, which has sharply defined edges. From Series II, the GTB/4 adopted the torque tube between engine and transmission. Several detail improvements were also made to the cooling system, exhaust, and suspension, making the car primarily a technical evolution.
Summarized from the cited sources; every figure was automatically verified against the sources.
Frequently asked questions about the Ferrari 275 GTB/4
When was the Ferrari 275 GTB/4 built?
The Ferrari 275 GTB/4 was built from 1966 to 1968.
How much power does the Ferrari 275 GTB/4 have?
Power of the Ferrari 275 GTB/4: 300 hp.
What engine does the Ferrari 275 GTB/4 have?
Engine of the Ferrari 275 GTB/4: V12 Tipo 226 with four overhead camshafts. It is mounted at the front.
How fast is the Ferrari 275 GTB/4?
Top speed of the Ferrari 275 GTB/4: 268 km/h.
How many Ferrari 275 GTB/4 were built?
330 units of the Ferrari 275 GTB/4 were built.
